Overview

FlowMCP is a Tool Catalog with pre-built API templates and a Knowledge Base for API workflows. It unifies access to APIs through two equal channels:

CLI — Direct access to Tools, Resources, Prompts, and Skills
MCP/A2A Server — Agents and MCP clients can use FlowMCP as a server (compatible with OpenClaw)

This document provides the conceptual foundation, positioning, terminology, and document index for the v4.2.0 specification.

Conformance Language

The key words “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “NOT RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are to be interpreted as described in BCP 14 [RFC2119] [RFC8174] when, and only when, they appear in all capitals, as shown here.

Some specification files in spec/v4.2.0/ are intentionally written in prose without normative keywords because they describe history, lifecycle, or conceptual background (this overview document, the migration guide, the schema lifecycle document). All other specification files use normative language and assume this conformance interpretation.

References:

RFC2119 — Key words for use in RFCs to Indicate Requirement Levels
RFC8174 — Ambiguity of Uppercase vs Lowercase in RFC 2119 Key Words
BCP 14 — Best Current Practice 14 (combined RFC2119 + RFC8174)

The Problem FlowMCP Solves

Not every data source is a clean REST API. The real world is messy — some APIs have quirks, some tasks require combining multiple APIs, and some data lives behind websites with no API at all. FlowMCP provides a solution for each scenario:

Data Source Type	Challenge	FlowMCP Solution
Complete REST API	Standard endpoints, predictable responses	Tool (deterministic)
API with peculiarities	Rate limits, pagination, unusual auth, response quirks	Tool + Prompt
Multiple APIs combined	Cross-provider workflows, data enrichment chains	Agent-Prompt (Workflow)
Website without API	Data locked in HTML, no programmatic access	Prompt (Instructions)

The key insight: not everything can be solved deterministically. A clean API call is deterministic — combine three APIs or scrape a website, and you need instructions for an LLM. FlowMCP covers both sides.

What FlowMCP Offers

FlowMCP provides two categories of primitives: deterministic building blocks that always behave the same way, and non-deterministic guidance that helps LLMs combine those building blocks effectively.

FlowMCP provides five primitives: Tools, Resources, Prompts, Skills, and Selections. Tools, Resources, and Prompts are defined in main.tools, main.resources, and main.prompts. Skills are a top-level entity that lives outside main and is scoped to a namespace, selection, or agent — never main.skills (forbidden in v4.0.0, see VAL016). Selections are curated subsets that bundle tools/resources/prompts/skills for agent loading. Tools and Resources are deterministic — same input always produces the same result. Prompts and Skills are non-deterministic — they guide LLMs on which tools to call, in which order, how to pass results between them, and when to fall back to alternative providers. Prompts are explanatory (describing a namespace or workflow), while Skills are instructional (step-by-step procedures with typed inputs and outputs). Together, they encode knowledge that would take hours to figure out manually.

Partial Validatability

Different primitives have different levels of validatability. FlowMCP embraces this spectrum rather than pretending everything is fully testable:

Primitive	Validatable?	What Can Be Validated
Tools	Completely	Schema structure, parameter types, output format, live API tests (minimum 3 deterministic test cases)
Resources	Completely	SQLite schema creation, query execution, parameter binding, result format
Prompts	Partially	Tool references resolve, parameter syntax `{{type:name}}` is valid, `references` entries exist
Skills	Partially	Placeholder syntax `{{type:name}}` is valid, `requires.tools` and `requires.resources` resolve, typed input/output structure
Selections	Partially	Structure valid, all referenced Primitives resolvable (SEL001–SEL003)
Agents	Partially	Manifest structure (`agent.mjs` with `export const agent`), tool references exist, `expectedTools` (deterministic), `expectedContent` (partially — LLM output varies)

This is a feature, not a limitation. Tools and Resources are the deterministic anchor. Prompts, Skills, and Agents build on that anchor but acknowledge that LLM behavior introduces variability.

Core Principles

1. Everything would be possible without FlowMCP

FlowMCP saves time through pre-built templates. Every tool, prompt, and agent definition encodes knowledge that a developer could acquire by reading API docs, experimenting with endpoints, and writing integration code. FlowMCP packages that work so it does not need to be repeated.

2. Providers AND Agents are important

Providers deliver data — one namespace per API source, model-neutral, reusable. Agents bundle tools from multiple providers for a specific task — purpose-driven, model-specific, opinionated. Neither is more important than the other. Providers are the building blocks, Agents are the compositions.

3. LLM-First

The specification MUST be written so an LLM can import it as plaintext and write tools itself. Schema files are .mjs with named exports — no build steps, no binary formats, no complex inheritance. An LLM reading a schema file SHOULD immediately understand what it does.

4. Token efficiency

Correct structure upfront saves LLM time and tokens at runtime. Shared lists avoid repeating enum values across schemas. Prompt placeholders reference tools by ID instead of duplicating descriptions. Agent manifests declare exactly which tools are needed — no discovery overhead.

5. Seamlessly extensible

From local .env auth today to OAuth in the future. The architecture does not lock into a single auth mechanism. API keys in environment variables work now. OAuth flows, token refresh, and delegated auth can be added without breaking existing schemas.

LLM-First Design Philosophy

Open Structures Instead of Strict Hierarchies

Traditional API frameworks optimize for machine enforcement — strict types, deep inheritance, access control layers. FlowMCP optimizes for LLM comprehension:

Aspect	Traditional Architecture	LLM-First Architecture
File format	JSON/YAML with strict schema	`.mjs` with named exports — readable as plaintext
Composition	Import chains, class hierarchies	Flat references by ID, no nesting
Access control	Roles, permissions, scopes	None — FlowMCP is local, the user controls access
Categorization	Enforced taxonomy	Efficiency categorization, not access control
Extension	Plugin APIs, hook systems	Add a new `.mjs` file, reference it in registry

Why This Works

FlowMCP is local software. It runs on the developer’s machine or in their infrastructure. There is no multi-tenant permission system because there is only one tenant. The provider/agent categorization exists for efficiency — helping LLMs find the right tool quickly — not for access control.

Consequences for Architecture

Because the system is open and local, an LLM can create new agents at runtime by combining existing provider tools:

Shared lists and provider-prompts are available as context at every step. The LLM does not need to discover capabilities through trial and error — it reads the catalog.

Three-Level Architecture

FlowMCP organizes its catalog in three levels. The root level holds shared resources. Provider and Agent levels are peers that both reference root-level data:

Root Level

Shared Lists — Reusable, versioned value lists (EVM chains, country codes, trading pairs). Shared lists live exclusively at root level and are injected into schemas at load-time.
Shared Helpers — Utility functions available to all schemas via dependency injection.
registry.json — The catalog manifest listing all providers, agents, and shared lists.

Provider Level

One API provider per namespace. Each provider directory contains:

Tools — Deterministic API endpoint wrappers (main.tools)
Resources — Local SQLite data access (main.resources)
Prompts — Model-neutral guidance for using this provider’s tools (main.prompts)

Provider-level prompts are model-neutral — they describe how to use the provider’s tools without assuming a specific LLM. Any model can benefit from them.

Agent Level

A complete, purpose-driven definition that bundles tools from multiple providers for a specific task. Each agent includes:

Tools — Cherry-picked from multiple providers
Prompts — Model-specific, tested against a specific LLM
Model — The target LLM (e.g. claude-sonnet-4-20250514, gpt-4o)
System Prompt — The agent’s persona and behavioral instructions

Agent-level prompts are model-specific — they are written and tested for a particular LLM, leveraging its strengths and working around its weaknesses.

Terminology

Term	Definition
Schema	A `.mjs` file with two named exports: `main` (static) and optionally `handlers` (factory function). Defines tools, resources, and/or prompts.
Tool	A single API endpoint within a schema (formerly called “Route” in v2). Maps to the MCP `server.tool` primitive. Each tool has parameters, a method, a path, and optional handlers. Defined in `main.tools`.
Route	Deprecated alias for Tool. `main.routes` is accepted in v3.0.0 with a deprecation warning but will be removed in v3.2.0. Schemas MUST NOT define both `tools` and `routes`.
Resource	Local data access via SQLite databases (in-memory or file-based) and Markdown documents. Maps to the MCP `server.resource` primitive. Defined in `main.resources`. See `13-resources.md`.
Provider-Prompt	A model-neutral prompt explaining a single namespace. Describes how to use one provider’s tools effectively without assuming a specific LLM model.
Agent-Prompt	A model-specific prompt tested against a specific LLM model. Contains tool combinatorics, chaining instructions, and fallback strategies.
Skill	A self-contained instruction set for AI agents. Maps to the MCP `server.prompt` primitive. Defined as a `.mjs` file with `export const skill` containing typed metadata (including `type: 'namespace' \| 'selection' \| 'agent'`), input/output declarations, and Markdown instructions with `{{type:name}}` placeholders. Lives in `providers/{ns}/skills/`, `selections/{name}/skills/`, or `agents/{name}/skills/` depending on `type`. NOT defined under `main.skills` (forbidden in v4.0.0). See `14-skills.md`.
Content Placeholder	`{{type:name}}` syntax for dynamic content in prompts and skills. Types: `{{tool:name}}` references a tool, `{{resource:name}}` references a resource, `{{input:key}}` references an input parameter. Replaces the deprecated `[[...]]` syntax from earlier revisions.
Namespace	Provider identifier, lowercase letters only (e.g. `etherscan`, `coingecko`). Groups schemas by data source.
Handler	An async function returned by the `handlers` factory. Performs pre- or post-processing for a tool or resource query. Receives dependencies via injection.
Modifier	Handler subtype: `preRequest` transforms input before the API call, `postRequest` transforms output after the API call (or after a resource query).
Shared List	A reusable, versioned value list (e.g. EVM chain identifiers, country codes) referenced by schemas and injected at load-time.
Agent	A complete, purpose-driven definition with tools, prompts, skills, model, and behavior. Defined as `agent.mjs` with `export const agent` containing all metadata, tool references, model binding, system prompt, and tests. Bundles tools from multiple providers for a specific task. Replaces “Group” from v2. See `06-agents.md`.
Catalog	A named directory containing a `registry.json` manifest with shared lists, provider schemas, and agent definitions. The top-level organizational unit.
Main Export	`export const main = {...}` — the declarative, JSON-serializable part of a schema. Contains `tools`, `resources`, and `prompts`. Hashable for integrity verification. Schemas use `export const main`; agents use `export const agent` (see Agent).
Handlers Export	`export const handlers = ({ sharedLists, libraries }) => ({...})` — factory function receiving injected dependencies. Subject to security scanning.

Specification Document Index

Document	Title	Description
`00-overview.md`	Overview	Vision, architecture, terminology, design principles (this document)
`01-schema-format.md`	Schema Format	File structure, main/handlers split, tool definitions, naming conventions
`02-parameters.md`	Parameters	Position block, Z block validation, shared list interpolation, API key injection, resource and prompt parameters
`03-shared-lists.md`	Shared Lists	List format, versioning, field definitions, filtering, resolution lifecycle
`04-output-schema.md`	Output Schema	Response type declarations, field mapping, flattening rules
`05-security.md`	Security Model	Zero-import policy, library allowlist, static scan, dependency injection
`06-agents.md`	Agents	Agent manifest format (`agent.mjs` with `export const agent`), tool cherry-picking, model binding, system prompts, integrity verification
`07-tasks.md`	Tasks	Deferred — MCP Tasks integration placeholder
`08-migration.md`	Migration	v1.2.0 to v2.0.0 and v2.0.0 to v3.0.0 migration guides, backward compatibility
`09-validation-rules.md`	Validation Rules	Complete validation checklist for schemas, lists, agents, resources, and prompts
`10-tests.md`	Tests	Test format for tools and resources, design principles, response capture lifecycle, output schema generation
`12-prompt-architecture.md`	Prompt Architecture	Provider-Prompts (model-neutral), Agent-Prompts (model-specific), placeholder syntax, cross-schema composition
`13-resources.md`	Resources	SQLite resource format, queries, parameters, SQL security, handler integration
`14-skills.md`	Skills	Skill `.mjs` format (`export const skill`), `{{type:name}}` placeholders, typed input/output, versioning, validation rules
`15-catalog.md`	Catalog	Catalog manifest, registry.json, named catalogs, import flow
`16-id-schema.md`	ID Schema	ID format `namespace/type/name`, short form, resolution rules
`17-selections.md`	Selections	Curated tool subsets for agent loading — `whenToUse`, reference resolution, SEL validation rules
`18-prefill.md`	Prefill	Pre-execute tools before delivering a Skill — prefill array, execution order, result injection
`19-mcp-integration.md`	MCP Integration	`meta` block for Tools (isReadOnly, isConcurrencySafe, isDestructive, searchHint, aliases, alwaysLoad)
`20-validation-strategy.md`	Validation Strategy	Validation pipeline, grade system, quality thresholds, CI integration
`21-schema-lifecycle.md`	Schema Lifecycle	Six lifecycle stages, API-test special rule for static schemas, partial schema policy

Design Principles

1. Deterministic over clever

Same input always produces the same API call. No randomness, no caching heuristics, no adaptive behavior inside the schema layer. If a schema’s preRequest handler receives the same payload, it must produce the same struct every time.

2. Declare over code

Maximize the main block, minimize handlers. Every field that can be expressed declaratively (URL patterns, parameter types, enum values) must live in main. Handlers exist only for transformations that cannot be expressed as static data — never for logic that could be a parameter default or a path template.

3. Inject over import

Schemas receive data through dependency injection, never import. A handler that needs EVM chain data does not import a chain list — it receives sharedLists.evmChains via the factory function. Libraries are declared in requiredLibraries and injected by the runtime from an allowlist. Schema files contain zero import statements.

4. Hash over trust

Integrity verification through SHA-256 hashes. The main block is hashable because it is pure JSON-serializable data. Agents store hashes of their member tools. Changes to a schema invalidate the hash, signaling that review is needed.

5. Constrain over permit

Security by default, explicit opt-in for capabilities. Schema files have zero import statements — all dependencies are declared in requiredLibraries and injected from a runtime allowlist. The security scanner rejects schemas with forbidden patterns at load-time, before any tool is exposed to an AI client.

Version History

Version	Revision	Date	Changes
1.0.0	—	2025-06	Initial schema format. Flat structure with inline parameters and direct URL construction.
1.2.0	—	2025-11	Added handlers (preRequest/postRequest), Zod-based parameter validation, modifier pattern for input/output transformation.
2.0.0	—	2026-02	Two-export format (`main` + `handlers` factory). Dependency injection via allowlist. Shared lists for reusable values. Output schema declarations. Zero-import security model. Groups with integrity hashes. Maximum routes reduced from 10 to 8.
3.0.0	1.0	2026-03	Four primitives: Tools (renamed from Routes), Resources (SQLite), Prompts (model-neutral/model-specific guidance), Skills (`.mjs` instructional workflows). `main.routes` deprecated in favor of `main.tools`. `flowmcp-skill/1.0.0` versioning for skills. Group type discriminators for resources and skills.
3.0.0	8.0	2026-03	Three-level architecture (Root/Provider/Agent). Groups renamed to Agents with `agent.mjs` manifest format (`export const agent`). Prompt architecture with Provider-Prompts (model-neutral) and Agent-Prompts (model-specific). Catalog with registry.json. Unified placeholder syntax `{{type:name}}` (replaces deprecated `[[...]]`). ID schema `namespace/type/name`. Test minimum increased to 3. Agent tests with `expectedTools`/`expectedContent`.
3.1.0	1.0	2026-03	Resources: Two SQLite modes (`in-memory` with `readonly: true`, `file-based` with WAL). Origin system (`global`, `project`, `inline`) replaces pseudo-paths. `better-sqlite3` replaces `sql.js`. `getSchema` MUST for both modes. `runSql` auto-injected. Max queries increased to 8. Block patterns removed. `source: 'markdown'` resource type with parameter-based access. Folder renamed `data/` to `resources/`. All fields required. Prompts: `contentFile` field for Provider-Prompts (content in external file). `references` field required (empty array when none). `about` convention (SHOULD) for Provider-Schemas and Agent-Manifests.

What Changed

v4.2.0

The v4.2.0 release adds remote-data resources, a fifth primitive, and richer agent validation:

HTTP Resources — source: 'http' references remote files (typically SQLite databases) fetched via HTTPS and cached locally. Validated by RES024 (HTTPS required). See 13-resources.md.
Selection primitive — A fifth primitive: a named collection of Tools, Resources, Prompts, and Skills that belong together thematically, activated as a coherent set. See 17-selections.md.
Extended Agent rules — agent.selections references MUST resolve to valid Selection IDs (AGT030). elicitation.maxRounds MUST be a positive integer (AGT031). See 06-agents.md.

v4.0.0

The v4.0.0 release establishes the major-4 baseline with a mandatory MCP integration layer:

Required meta block per Tool — Every Tool MUST declare isReadOnly, isConcurrencySafe, isDestructive, searchHint, aliases, and alwaysLoad (VAL100–VAL106). Missing meta is a validation error.
Skills as a scoped primitive — main.skills is removed. Skills are namespace-, selection-, or agent-scoped instead. See 14-skills.md.
Enum / Shared List enforcement — Enum values matching a Shared List MUST use {{listName:alias}} rather than hardcoded duplicates (VAL107).
Unified spec version — Skills and agents adopt flowmcp/4.0.0 as the unified version identifier.

The migration path from v3.0.0 to v4.0.0 is documented in 08-migration.md.

v3.1.0

The v3.1.0 release enhances Resources and Prompts with production-ready features:

Resources

Two SQLite modes — mode: 'in-memory' (readonly via better-sqlite3 readonly: true) and mode: 'file-based' (writable via WAL mode). Clear separation instead of implicit read-only.
Origin system — origin: 'global', origin: 'project', origin: 'inline' replace pseudo-paths (~/.flowmcp/data/, ./data/). Explicit storage locations with clear resolution rules.
better-sqlite3 runtime — Replaces sql.js as the unified SQLite runtime. Native C bindings, real readonly: true flag, WAL mode for concurrent writes.
getSchema is MUST — Required for both modes (previously SHOULD). Schema authors MUST define it. CLI uses it to create databases for file-based mode.
runSql auto-injected — Runtime automatically adds runSql. SELECT-only for in-memory, all statements for file-based.
Max queries increased to 8 — 7 schema-defined (including getSchema) + 1 auto-injected runSql.
Block patterns removed — readonly: true handles in-memory security at DB level. No more SQL pattern matching.
Markdown resources — source: 'markdown' with parameter-based access (section, lines, search). Intended for API documentation shipped with schemas.
Folder renamed — resources/ replaces data/.
All fields required — No defaults, no optional fields.
Backup strategy — Automatic .bak copy before first write for file-based databases.

Prompts

contentFile for Provider-Prompts — Provider-Prompt definitions live in main.prompts. Content is loaded from external .mjs files via the new contentFile field. Content files export export const content.
references required — The references field is now required for both prompt types. Empty array [] when no references.
about convention — Reserved prompt name (SHOULD) for both Provider-Schemas and Agent-Manifests. Entry point to a namespace or agent.

The migration path for existing resources is documented in the schema migration notes. Existing schemas using database paths and data/ folders need to adopt the origin system.

v3.0.0

The v3.0.0 release transforms FlowMCP from a tool catalog into a complete API knowledge platform covering all four primitives (Tools, Resources, Prompts, Skills):

Tools replace Routes — main.tools is the primary key. main.routes is accepted as a deprecated alias with a warning (removed in v3.2.0). Schemas MUST NOT define both tools and routes.
Resources — Embedded SQLite databases for local, deterministic data access. Defined in main.resources. See 13-resources.md.
Skills — Self-contained instruction sets for AI agents. Defined as .mjs files with export const skill and {{type:name}} placeholders. In v4.0.0 Skills are namespace/selection/agent-scoped (see 14-skills).
Groups renamed to Agents — Groups evolve into full agent manifests (agent.mjs with export const agent) with model binding, system prompts, and purpose-driven tool selection. See 06-agents.md.
Prompt Architecture — Two-tier prompt system: Provider-Prompts (model-neutral, single namespace) and Agent-Prompts (model-specific, multi-provider workflows). Unified {{type:name}} placeholder syntax (replaces deprecated [[...]]). See 12-prompt-architecture.md.
Catalog with registry.json — Named catalogs with a manifest file listing all providers, agents, and shared lists. Enables import and distribution. See 15-catalog.md.
ID Schema — Unified namespace/type/name format for referencing tools, resources, prompts, and skills across the catalog. Short form for common cases. See 16-id-schema.md.
Test minimum increased to 3 — Every tool MUST have at least 3 deterministic test cases (up from 1 in v2).
Agent tests — expectedTools validates which tools the agent selects (deterministic). expectedContent validates LLM output (partially deterministic).
0-tool schemas are valid — Resource-only, prompt-only, or skill-only schemas are allowed.
Three-level architecture — Root (shared lists, helpers, registry), Provider (one API per namespace), Agent (purpose-driven compositions).

The migration path from v2.0.0 to v3.0.0 is documented in 08-migration.md.

v2.0.0

The v2.0.0 release restructures the schema format around a fundamental insight: the declarative parts of a schema SHOULD be separable from the executable parts. This enables:

Integrity hashing of the main block without including function bodies
Security scanning of the handlers block as an isolated concern
Shared lists that inject reusable data at load-time instead of hardcoding enum values
Output schemas that declare expected response shapes for downstream consumers
Groups that compose tools across schemas with verifiable integrity

The migration path from v1.2.0 to v2.0.0 is documented in 08-migration.md.

Related: 01-schema-format.md, 06-agents.md, 17-selections.md, 15-catalog.md
